Copper Wire Shielding Braids

Manufacturer of Copper Wire Shielding Braids, Copper Wire Braided Sleeves, Copper Braided Sleeves, Tinned Copper Shielding Braids, Wiring Harness Accessories, Tubular Copper Braids, Tubular Copper Braided Sleeves, Earthing Material In India

OMKAR manufactures best quality Copper Wire Braided Strips and Other Metal Wire Braided Strips. Number of strands of bright annealed Copper Wire bunched together & then braided into tubular hollow form and then flattened immediately on same machine to get required width & thickness. These Flexible Copper Flat Braids are available in Bare Copper and With Tin or Silver Plating. Single Wire Gauge option is 30 SWG to 42 SWG.

List of standard sizes of Copper Wire Shielding Braids

Former OD	Coverage	Usable OD ( mm )		Item Code
MM	Percentage	Max	Min	Sr. No.
3	80% - 90%	5	2	OFS-0300
4	80% - 90%	6	3	OFS-0400
5	80% - 90%	8	4	OFS-0500
6	80% - 90%	12	5	OFS-0600
8	80% - 90%	14	6	OFS-0800
10	80% - 90%	16	8	OFS-1000
12	80% - 90%	18	10	OFS-1200
16	80% - 90%	21	13	OFS-1600
20	80% - 90%	25	17	OFS-2000
